ADAS AND ACCESSORIZATION
Designing and Installing Products to Ensure ADAS Compatibility
››› Exterior modifications such as aftermarket bumpers, valences, or even a simple vinyl wrap can degrade ADAS's ability to "see" through it, so sensor location needs to be taken into account before the installation takes place.
In a past issue of SEMA News, we reviewed a SEMA Education seminar that discussed the challenges and opportunities posed to the specialty-equipment market by the proliferation of advanced driver assistance systems (ADAS) on OE vehicles ("ADAS and The Art of Vehicle Customization," May 2022). In the article, we discussed the proper procedures to follow when lifting or lowering a vehicle. This article now takes a look at a follow-up session, "Modding Vehicles With ADAS," which aimed to provide insight for designers and manufacturers of exterior dress-up and bolt-on components who want to make sure their products are ADAS-compatible.
Hosted by Nick Dominato, senior vice president of product for Repairify, the session reviewed some basic ADAS features and what companies need to keep in mind when designing their products to work with ADAS, what restylers should know when installing them, and to ensure proper recalibration of those systems once installation is complete.
Working With Body Kits and Accessories
For this seminar, Dominato chose to focus on ADAS' park sensors and front and rear (blind spot) radar sensors—"areas where we typically add a front fascia, a grille guard or a front or rear bumper," he explains. This type of modification "typically doesn't affect the camera, but it does affect the park sensors and the radar sensors that are located behind the bumper."
Start with park sensors. According to Dominato, they are very susceptible to blockages. "Park sensors are typically not located behind the bumper, so if you don't put anything directly in front of them, they'll generally be fine."
The key components for accessorizers, then, are the radar sensors. These are
typically located either behind the bumpers, behind the grille or embedded in the taillight housings. As engineered, the sensors do have the ability to "see through" the factory plastic bumpers, but the bumper covers do affect the operation of the radar systems. Specifically, the sensors are designed to work with the OE bumper's outer fascia.
››› Metal objects that protrude a distance from the vehicle, such as a brush guard or winch bumper, present their own set of challenges, and designers and installers need to take the sensors' operating angles into consideration when R&D'ing exterior bolt-ons so as to minimize sensor interference.
How Modifications Affect ADAS
In short, placing something in front of the radar will affect the sensor in three ways:
Power Loss: "Automakers generally accept about a 10% reduction in range when they put a bumper cover in front of that radar sensor," Dominato said, and sensors are designed with that level of imperfection in mind.
Sensitivity Loss: Installing a body panel in front of the radar is going to create "noise" and interference that will reduce the sensitivity of the sensor on the margin. In terms of its ability to detect road objects, "that giant dump truck in front of you that weighs 15,000 lbs. won't matter," Dominato said, "We have to think on the margins—that marginal object with a smaller radar cross-section, that's going to be what's affected."
Wave Distortions: This can be affected by the shape of the bumper cover. A concave or other angular-shaped fascia, for instance, can distort the radar wave. "When the radar passes through plastic or metal, it will actually change the wave of the radar sensor if the bumper cover is angled because it changes the shape of the radar wave," Dominato explained. This can cause radar to "read" an object as being slightly to the left or right of its actual location.
Another key element: Radar performance can be degraded without launching an error code or engaging a dash light. "Just because adaptive cruise control works because it can 'see' that dump truck a hundred meters ahead, it doesn't mean it's going to work on the that marginal object." This could be a pedestrian exiting the curb or cyclist in a bike lane, both of which possess a much smaller cross-section for the radar system to identify."
The "Magic Area" and How to Work With It
When integrating aftermarket fascias, bumpers and exterior bolt-ons with ADAS systems, an important thing to take into consideration is the so-called "magic area" known as the radar projection area, i.e., the origin point of the radar signal. Manufacturers typically design their ADAS radar systems with an initial projection area of approximately 12x12 in. with the realization that the projection area increases as the radar signal emanates outward from the vehicle.
Starting with plastic components such as front fascias or bumpers, the key for aftermarket manufacturers is to design their products as close to identical to OE spec for material composition, thickness and curvature within the radar projection area. "You want to mimic the OEM bumper cover as best you can within that 12x12 projection area," Dominato recommended.
Metal components such as grille guards and winch bumpers pose a different challenge, and Dominato suggested the following steps: "The first thing to do is find out where the radar sensor is," which sounds easy enough until you realize there's no industry standardization for this, and that sensor location will vary by manufacturer.
"Sometimes it will be behind the emblem, or slightly offset from the emblem, and sometimes it's on the lower portion of the grille, and sometimes, as is the case with the Ford F-150, it's offset much lower to one side or the other," Dominato observed.
Next, apply the same "12x12" principle to the winch bumper as you would with a plastic fascia, with the aim of being as precise as possible in your measurements. "The OE manufacturers do not allow any sanding, filling, primer, welding or repair work at all within that radar projection area," Dominato emphasized. "So if plastic welding and Bondo aren't allowed within that radar area, imagine what happens when you place a piece of metal in front of it. It's going to cause a ton of interference."
